Product Highlights:

Auto Dimming control backlight brightness from 100% to 20%
1200nits High Brightness
LED Backlight with High Contrast
Ruggedized IP65 Proof Steel Enclosures (IP54 Bottom)
Touchscreen optinal







Rugged Marine Grade, High Brightness 46" LCD Large Yacht Displays and Monitors (Model: M4600)

SunTronics Product line, featuring innovative All-Weather Sunlight Readable LCD technology, provides the highest-quality Sunlight Readable image available in Out Door Envirnoment. These Industrial grade Outdoor displays have the exemplary resolution and brightness you've come to expect from SunTronics. GS technology delivers stunning images for use in applications such as: Digital Signage, Ski Resorts, Retail/ Restaurants, Golf Course, Gas Stations, Shopping Malls, Restaurants and Outdoor Signs.

M Series is a Rugged Marine Grade High Brightness LCD. MSeries includes with an IP54 Water Proof steel enclosures and lastest LED highbrightness technology brightness up to 1200nits. Operating temp from Operating Temp 5F to 110F. (Optional add heater reach to -22F). Its perfectly fit for Large Yacht Displays and Monitors.

Features:

• Auto Dimming control backlight brightness from 100% to 20%
• 1200 High Brightness LCD Panel
• LED Backlight with High Contrast
• Ruggedized IP65 Proof with Steel Enclosures (IP54 Bottom)
• Optional DC to DC power input acceptable
• Touchscreen optinal
• IP65 OSD front panel Design

Specs:

Display Size: 46" (1018.353 x 572.544 mm2)
Panel Type: TFT LCD
Resolution Capabilities: 1920 x 1080 RGB
Color: 16.7 M
Pixel Pitch: 0.5302 x 0.5302 mm
Horizontal Freq. 62.13KHz ~ 75.6KHz
Vertical Freq. 57Hz ~ 63Hz
Contrast Ratio: 2000:1 Typical
Brightness: 1200 cd/m2, LED backlight enhanced
Dimming range: Auto dimming by light sensor
Viewing Angle: 89/89/89/89
Response: Time 15ms / 5ms
Interface: VGA, AV, S-video, HDMI (round connector IP66)
Video System: PAL/SECAM/NTSC-3.58, NTSC-4.43, PAL-60 (reserved for internal media player)
Remote control: Support for full OSD features
Operate Voltage: AC 100 ~ 240V 60/50Hz
Power Consumption: 750 Watt for complete monitor, Additional 120 Watt for optional Heater
Stand by mode: 25 W or less
Enclosure: Steel Enclosures, IP54
Protection: 4--6mm Vandal glass at the front
Accessories: AC Power Cord, Remote Control.
VGA cable x 1, S-Video cable x 1, HDMI Cable x1
Environmental Operating temperature -10 ~ 45C, wide temp -30 ~ 45C
Options: Operating Humidity 10% ~ 85%
Storage temperature -30 ~ 55C
Storage Humidity 5% ~ 95%
